Lumitec 101684 CE Certified

PICO S8 is designed to monitor the output of up to 8 SPST switches (toggle, rocker, momentary, etc.) and signal the Lumitec POCO Digital Lighting Control System (POCO 3 or greater) when a switch is flipped, pressed, or released. POCO can be configured to use the signal from the PICO S8 to trigger any pre-set digital command to its connected lights. This means that, with the PICO S8, a mechanical switch can be given full digital control over Lumitec lights. Secure PICO S8 to desired surface with the provided #6 mounting screws. Use Mounting Template provided to pre-drill pilot holes. Most applications will require a drill bit sized larger than the minimum screw diameter but smaller than the maximum thread diameter. When choosing where to mount the PICO S8, consider proximity to the POCO and to the switches. When possible, minimize the length of wire runs. Also consider the visibility of the indicator LED on the PICO S8, which can be useful during the setup to determine the status of the S8.

Features & Benefits

• Pico expansion modules extend the power and reach of the poco digital lighting control system making it possible to control other manufacturers’ luminaires, lighting accessories
• Provides the ability to assign poco virtual switch commands to physical mechanical switches
• Mfd can remain on a dedicated screen, or even be turned off, and a physical switch will activate the virtual switch command through the poco module
• CE Certified
• Limited 3 year warranty

Specifications
