23845 Moroso Performance Oil Filter

After many Years of designing and testing racing oil systems and related components, we’ve determined what’s most important to oil filtration. Many filter manufacturers stress the importance of filtering the smallest particles out of your engine’s oil, with references to Micron Ratings of 10 or less for a filter’s efficiency. With the help of research performed by filtration technology experts, Moroso engineers have determined that particles smaller than 20 Microns in diameter are not large enough to produce engine wear. Furthermore, we’ve found that filters with extremely low micron ratings create an excessive pressure drop across the filter. They can be so restrictive that the filter by-pass valve can open. With the by-pass valve open, unknown to you, no filtration will occur! To maximize filter performance, Moroso racing oil filters have a rating of 27 Microns, which produces a maximum initial restriction of only 2.5 PSI when tested to SAE J806! The result is less pressure drop, more flow, less oil by-pass and maximum filtration performance important in severe racing conditions.

Pleated Element Design Increases Filtering Area

Roll Formed Threads For Precise, Tight Fit

Buna-N Gasket Compatible With All Racing Fuels And Lubricants

Extra Thick Back Plate Provides Added Protection Against Pressure Surges

Anti Drainback Valve Keeps Oil In Filter After Engine Shut Down

Filter Element Provides Maximum Flow With Minimal Pressure Drop

Non Porous, Metal End Caps Prevent Unfiltered Oil To By-Pass. Extra Thick Housing With Tuck Seam Withstands Higher Burst Pressure

Limited 90 Day Warranty
