Elevate your driving experience with the Fabtech 6in Basic Lift System designed specifically for the 2019 Chevy/GMC C1500 2WD. This premium lift kit combines advanced engineering with superior performance to enhance both on-road and off-road capabilities.

Key Features:

• Exceptional Driveability: Fabtech's world-renowned IFS suspension design minimizes bump steer throughout the suspension cycle, reducing drive fatigue and significantly improving vehicle handling.
• Cleansed Appearance: A near stock track width keeps the tires neatly tucked under the fenders, providing a sleek and clean look.
• Superior Steering: Proprietary steering knuckle geometry ensures an excellent lock-to-lock turning radius, perfect for maneuvering in tight spaces.
• Heavy-Duty Construction: Featuring 1/4" thick steel crossmembers with OE style alignment cam pins for easy adjustments, ensuring robustness and longevity.
• Coilover Shock Relocation: The factory coilover shocks are strategically relocated, allowing for full steering movement while achieving an impressive 6" lift.
• Rear Lift Accomplished: A 5" block and u-bolt system effectively lifts the rear, maintaining balanced suspension dynamics.
• Long Warranty: Comes with a complimentary 5 year/60,000 mile Powertrain Warranty for added peace of mind.

Enhanced Features:

• Arched Crossmembers: Designed for maximum ground clearance, enhancing off-road capabilities.
• Zero Bump Steer: Extended length ductile iron steering knuckles provide a smooth driving experience, reducing discomfort while navigating.
• Oversized Tie Rods: Replace stock units to accommodate larger tires for improved stability and performance.
• Stock Ride Quality: Heavy-duty lower mounts enable the factory coilovers to maintain a factory-like ride while providing the lift needed.
• Repositioned Sway Bar: 1/4" thick steel drop brackets reposition the front sway bar, allowing full cycle without binding for superior handling.

Compatibility:

• Fits Crew Cab, Short Bed models only.
• Not compatible with models equipped with Adaptive Ride Control.
• Does not fit 2019 Chevy Silverado LD or 2019 GMC Sierra Limited 1500 models. Use 2018 model application for these vehicles.

Tire Compatibility:

Designed to accommodate the following tire sizes with minor trimming:

• 35/12.50R18 on 18X9 Wheel with 5" Backspacing
• 35/12.50R20 on 20X9 Wheel with 5" Backspacing
• 295/65R20 on 20X9 Wheel with 5" Backspacing
• 295/70R18 on 18X9 Wheel with 5" Backspacing

Transform your Chevy/GMC 1500 2WD with the Fabtech 6in Basic Lift System and experience the perfect blend of performance, comfort, and style!
