Fabtech 14-18 GM C/K1500 w/OE Forged UCA 6in Basic System Gen II w/Rear Stealth Shocks

Fabtech 14-18 GM C/K1500 w/OE Forged UCA 6in Basic System Gen II w/Rear Stealth Shocks

Enhance your GM C/K1500's performance and aesthetics with the Fabtech 6in Basic System Gen II. This advanced suspension system is designed specifically for 2014-2018 models equipped with OE forged upper control arms, providing superior lift and stability for your vehicle.

Key Features:

• Factory Track Width Retention: Maintains proper tire placement under the fenders, ensuring a clean and streamlined appearance.
• Enhanced Front Sway Bar Functionality: Utilizes stock end links and mounting points, preserving the original leverage for optimal performance.
• Easy Installation: No CV spacers, impact struts, or add-a-leafs required, making the setup process quicker and simpler.
• Vibration Reduction: Front differential is relocated to minimize vibration at high 4WD speeds, enhancing driving comfort.
• Simplistic Coilover Spacer: Lift provided from the top of the shock, reducing installation time and complexity.
• Performance Rear Shocks: Equipped with Performance Twin Tubes for superior ride quality and handling.
• Durable Construction: All bracketry and skid plates are made from 1/4" thick steel, ensuring maximum strength and reliability.
• Improved Vehicle Stance: Levels the vehicle stance compared to the factory nose-down rake, providing a rugged, aggressive look.
• FMVSS 126 Compliance: Passes stability control functionality tests conducted by independent labs for peace of mind.

Tire and Wheel Compatibility:

This system is designed to accommodate a variety of tire and wheel combinations:

• Tire Size - 35/12.50R17 with 17x8 wheel (5" backspacing) with minor trimming
• Tire Size - 35/12.50R20 with 20x9 wheel (5" backspacing) with minor trimming
• Tire Size - 325/65R18 with 18x9 wheel (5" backspacing) with minor trimming

Important Notes:

• Not compatible with models equipped with factory Autoride shocks.
• Will not fit all-wheel-drive models.
• OEM wheels and tires cannot be used with this system.
• Does not fit standard cab models.
• Designed for vehicles with factory forged black steel upper control arms.

Upgrade your vehicle's suspension with the Fabtech 6in Basic System Gen II and experience enhanced performance, stability, and style on and off the road.
