Fabtech 11-16 Ford F350/450 4WD 8 Lug 6in Radius Arm System w/DL 4.0 Coilovers & Rear DL Shocks

Fabtech 11-16 Ford F350/450 4WD 8 Lug 6in Radius Arm System w/DL 4.0 Coilovers & Rear DL Shocks

Upgrade your Super Duty's front suspension with the Fabtech 6-inch Radius Arm System, designed specifically for the 2011-2016 Ford F350 and F450 4WD models. Experience unparalleled performance and durability with our cutting-edge Dirt Logic 4.0 Stainless Steel Coilover Conversion system.

Key Features:

• Robust Upper Coilover Mounts: Constructed with 1.75 diameter DOM tubing, these mounts replace factory coil spring mounts and provide a wider span across the frame for superior impact load distribution.
• Durable Lower Mounts: Made from 1/4'' thick steel, these mounts securely attach to the axle housing, ensuring solid support for the Dirt Logic 4.0 Coilovers.
• Advanced Damping Capability: The Dirt Logic 4.0 Stainless Steel Coilover piggyback reservoir shocks provide maximum front suspension damping for enhanced ride quality.
• Billet Sway Bar End Links: Features heim ends for improved articulation and durability.
• Quad Layer Limiting Straps: Designed to prevent over-extension and enhance the suspension's reliability.
• Rear Shocks Included: Comes equipped with 2.25 Dirt Logic Stainless Steel shocks for a balanced suspension system.

Compatibility:

This system is compatible with non-dually models only and allows for various tire and wheel sizes:

• Tire Size - 35/12.50R20 with 20X9 wheel and 5" backspacing (minor trimming may be required)
• Tire Size - 315/70R17 with 17X8 wheel and 4 1/2" backspacing (minor trimming may be required)
• Tire Size - 325/65R18 with 18X9.5 wheel and 4 3/4" backspacing (minor trimming may be required)

Additional Notes:

Front drive shaft modification may be required to clear the exhaust on gas motor models.

Elevate your truck's performance and ride quality with the Fabtech 6-inch Radius Arm System. Invest in a suspension upgrade that promises reliability and superior driving dynamics!
